- Description
-
Details
- Measurements: (Height) 106mm (Width) 232mm (Depth) 137mm
- Spout Dimensions: (Height) 55mm (Projection) 95mm
- Base Diameter: 50mm
- Pipe Centres: 180mm
- Main Construction Material: Brass
- Mount Type: Deck
- Handle Type: Paddle
- Connection Inlet: 3/4”BSP
- Connection Outlet: Flow Straightener
- Number of Tap Holes: 2
- Valve/Cartridge Type: 3/4” Ceramic Disc Valve - 1/4 turn
- Plumbing System Requirements: Suitable for all plumbing systems
- Minimum Dynamic Pressure (bar): 0.2 bar
- Maximum Dynamic Pressure (bar): 5 bar
- Maximum Hot Water Temperature °C: 65°C
- Maximum Static Pressure (bar): 10 bar
- Flow Type: Single
- Isolation Included: No
- Finish: Chrome
- Range: Hourglass
- Product Certifications: WRAS
Features:
- You really can count on Bristan taps as they are designed, engineered and tested to last with our precise glide and secure fix components plus a modern chrome finish, all under a 10 Year guarantee for peace of mind
- A chrome finish that will make a statement in any bathroom
- Long life and easy to use 1/4 turn ceramic disc valves
- Supplied with metal fixing nuts for added durability and to secure your tap in place
- Suitable for high and low pressure water systems
Flow Rates (l/min)
- 0.2bar - 18.3 (l/min)
- 0.5 bar - 28.9 (l/min)
- 1 bar - 40.8 (l/min)
- 3 bar - 70.7 (l/min)
- 5 bar - 91.3 (l/min)
- Additional Information
-
Additional Information
Installation Guide No Approvals WRAS Basic Dimensions (Height) 106mm (Width) 232mm (Depth) 137mm EAN Number 5014868019017 Guarantee 5 Years Pipe Centres Fixed at 180mm Manufacturer Bristan Minimum Recommended Pressure Low Pressure 0.2bar Valve Technology Ceramic Disc - Reviews
-
